## Introduction

This walkthrough tutorial is about how to set up Swagger with ASP.NET MVC API
by using Visual Studio 2015, and also provides steps on how to customize the
Swagger UI.

## What's Swagger?

Swagger could provide richer documentation for your API, but that's not all — it
provides tools to design, test, and document your API. Although this
blog just focuses on how to set up Swagger UI on Visual Studio 2015's ASP.NET
API project. ASP.NET MVC also has a Web API Helper page, but unlike Swagger,
which is more powerful with client generation, discoverability, and broader
developer support.

This blog will show how to use Swagger with an ASP.NET MVC API project and provide
a list of how-tos.

> With a Swagger-enabled API, you get interactive documentation, client SDK
> generation and discoverability.

```
Install-Package Swashbuckle
```

The following are a few resources related to Swagger.

- [swagger.io](http://swagger.io/)

- Swashbuckle

- swagger-codegen

- swagger-ui

- OpenAPI Specification

## Use Azure API App Template with Swagger

You can use Swagger with Visual Studio 2015, ASP.NET 4.5.2 Templates. Once you
use Visual Studio and create a web application using the Azure API App template, in
your solution you should see the following Swagger entry in the package file.

![](http://res.cloudinary.com/dmwrakaup/image/upload/v1458931625/vrtczaiykyxoxtecgloc.png)

You will find the NuGet library `Swashbuckle`, which is the .NET version of
Swagger. If you want to use the latest NuGet version, you can use NuGet to
uninstall the package and install the latest NuGet package again.

![](https://d1p0mp3f1fx0hz.cloudfront.net/_dp4q0c174.png)

### SwaggerConfig, EnableSwaggerUi, and Basic Configuration

After installing Swashbuckle, you will see a SwaggerConfig under your
App_Start folder. This `SwaggerConfig` is the starting point to enable
Swagger. If you already have the following content, then your setup is
done. We should see the API documentation generated by Swagger.

```
[assembly: PreApplicationStartMethod(typeof(SwaggerConfig), "Register")]

namespace WebApplication1
{
    public class SwaggerConfig
    {
        public static void Register()
        {
            var thisAssembly = typeof(SwaggerConfig).Assembly;

            GlobalConfiguration.Configuration

                .EnableSwagger(c =>
                    // {...
                    // this will enable swagger UI
                .EnableSwaggerUi(c =>
```

### Build the Solution and Check the URL

Navigate to `{yoururl}/swagger` or `{yoururl}/swagger/ui/index`.

You should be able to see the following Swagger UI documentation page. I
have two Web APIs, `TestController` and
`ValuesController`. As you can see, it contains a search feature
and you can try it out.

![](http://res.cloudinary.com/dmwrakaup/image/upload/v1458932570/vbbqw3dh7xbalqxmxlyd.png)

![](https://d1p0mp3f1fx0hz.cloudfront.net/_3cxww0sfn.png)

However, I also had the following questions when I first saw these pages
generated by Swagger.

- Can I change this API document's UI, including the logo and stylesheet?

- Can I add JavaScript to this?

- Can I change the URL instead of /swagger?

- Can I add my own page to this auto-generated page?

- Can I make certain Web APIs not show up?

- Can I turn the Swagger API documentation off in production, but keep it only in
  development?

I might not cover all these questions I have in mind, but I will give them a
try and list them here.

## Can I Use a Customized Stylesheet for Swagger?

Let's assume I want to change the following style, which changes the header
background color to `#704C8F`.

### 1. CSS File

```
.swagger-section #header {
    background-color: #704C8F;
    padding: 14px;
}
```

### 2. SwaggerConfig

```
.EnableSwaggerUi(c =>                   {
c.InjectStylesheet(Assembly.GetAssembly(typeof(WebApiApplication)), "WebApplication2.styles.swagger_test.css");
```

### 3. Global.asax

#### How the WebApiApplication Looks

The SwaggerConfig's InjectStyleSheet's first parameter needs to pass the
current application's assembly. The second parameter is a little tricky. The
filename `WebApplication2.styles.swagger_test.css` is
`Project Folder name`.`{folder name}` and the file name.

```
namespace WebApplication2
{
    public class WebApiApplication : System.Web.HttpApplication
    {
        protected void Application_Start()
        {
            AreaRegistration.RegisterAllAreas();
            GlobalConfiguration.Configure(WebApiConfig.Register);
            RouteConfig.RegisterRoutes(RouteTable.Routes);
        }
    }
}
```

#### 4. Styles File Location

Also, this is very important — you must set the file's Build Action to Embedded
Resource.

```

```

#### 5. After Steps 1–4, How the Page Looks

![](http://res.cloudinary.com/dmwrakaup/image/upload/v1458968917/vetiqfmu4mizsfyolm2h.png)

## Can I Add My Own JavaScript File to Swagger API Documents?

You are able to do it as follows. Assume you have a JavaScript file like this.

### 1. JavaScript

```
(function () {
    function init() {

        console.info("init for my swagger function");

        $("#explore").click(function () {
            alert("you clicked explore");
        });
    }

    init();
})();
```

### 2. JavaScript File Location and Build Action Property

```

```

### 3. SwaggerConfig Class

Set the JavaScript path as a string type like the following.

```
var myAssembly = Assembly.GetAssembly(typeof(WebApiApplication));
   c.InjectJavaScript(myAssembly, "WebApplication2.js.swagger_test.js");
```

### 4. Done, Check the Page

When the page loads, you can see the JavaScript console message. Now you can
add JavaScript to the page. My next question is: can I change the default HTML?

![](http://res.cloudinary.com/dmwrakaup/image/upload/v1458969860/h3novy9llbwau4kearez.png)

## Now, We Know We Can Change JavaScript, CSS — Can We Change the Entire HTML?

Yes, and the main features will still work if you use Swagger's existing
JavaScript. The following is how we can do it.

### 1. HTML Files

This time I want to add two HTML files. After creating these HTML files, you also have to
change the Build Action to Embedded Resource again.

![](http://res.cloudinary.com/dmwrakaup/image/upload/v1458971711/evgs4ci6wclqwpqpirxg.png)

swagger_test.html

```
Bomm!!!!
```

OtherVersion.html

```
<!DOCTYPE html>



    Swagger UI My Own Version




























    $(function () {
      var url = window.location.search.match(/url=([^&]+)/);
      if (url && url.length > 1) {
        url = decodeURIComponent(url[1]);
      } else {
        url = "http://petstore.swagger.io/v2/swagger.json";
      }

      // Get Swashbuckle config into JavaScript
      function arrayFrom(configString) {
        return (configString !== "") ? configString.split('|') : [];
      }

      function stringOrNullFrom(configString) {
        return (configString !== "null") ? configString : null;
      }

      window.swashbuckleConfig = {
        rootUrl: 'http://localhost:65343',
        discoveryPaths: arrayFrom('swagger/docs/v1'),
        booleanValues: arrayFrom('true|false'),
        validatorUrl: stringOrNullFrom('http://localhost:65343/validator'),
        customScripts: arrayFrom('ext/WebApplication2-js-swagger_test-js'),
        docExpansion: 'none',
        oAuth2Enabled: ('false' == 'true'),
        oAuth2ClientId: '',
        oAuth2ClientSecret: '',
        oAuth2Realm: '',
        oAuth2AppName: '',
        oAuth2ScopeSeperator: ' ',
        oAuth2AdditionalQueryStringParams: JSON.parse('{}')
      };

      // Pre load translate...
      if(window.SwaggerTranslator) {
        window.SwaggerTranslator.translate();
      }
      window.swaggerUi = new SwaggerUi({
        url: swashbuckleConfig.rootUrl + "/" + swashbuckleConfig.discoveryPaths[0],
        dom_id: "swagger-ui-container",
        booleanValues: swashbuckleConfig.booleanValues,
        onComplete: function(swaggerApi, swaggerUi){
          if (typeof initOAuth == "function" && swashbuckleConfig.oAuth2Enabled) {
            initOAuth({
              clientId: swashbuckleConfig.oAuth2ClientId,
              clientSecret: swashbuckleConfig.oAuth2ClientSecret,
              realm: swashbuckleConfig.oAuth2Realm,
              appName: swashbuckleConfig.oAuth2AppName,
              scopeSeparator: swashbuckleConfig.oAuth2ScopeSeperator,
              additionalQueryStringParams: swashbuckleConfig.oAuth2AdditionalQueryStringParams
            });
          }

          if(window.SwaggerTranslator) {
            window.SwaggerTranslator.translate();
          }

          $('pre code').each(function(i, e) {
            hljs.highlightBlock(e)
          });

          addApiKeyAuthorization();

          window.swaggerApi = swaggerApi;
          _.each(swashbuckleConfig.customScripts, function (script) {
            $.getScript(script);
          });
        },
        onFailure: function(data) {
          log("Unable to Load SwaggerUI");
        },
        docExpansion: swashbuckleConfig.docExpansion,
        jsonEditor: false,
        apisSorter: null, // default to server
        defaultModelRendering: 'schema',
        showRequestHeaders: false
      });

      if (window.swashbuckleConfig.validatorUrl !== '')
        window.swaggerUi.options.validatorUrl = window.swashbuckleConfig.validatorUrl;

      function addApiKeyAuthorization(){
        var key = encodeURIComponent($('#input_apiKey')[0].value);
        if (key && key.trim() != "") {
          var apiKeyAuth = new SwaggerClient.ApiKeyAuthorization("api_key", key, "query");
            window.swaggerUi.api.clientAuthorizations.add("api_key", apiKeyAuth);
            log("added key " + key);
        }
      }

      $('#input_apiKey').change(addApiKeyAuthorization);

      // if you have an apiKey you would like to pre-populate on the page for demonstration purposes...
      /*
        var apiKey = "myApiKeyXXXX123456789";
        $('#input_apiKey').val(apiKey);
      */

      window.swaggerUi.load();

      function log() {
        if ('console' in window) {
          console.log.apply(console, arguments);
        }
      }
  });



    Damn, I love this! Swagger!





```

### 2. SwaggerConfig for HTML

```
c.CustomAsset("swagger_test", myAssembly, "WebApplication2.html.swagger_test.html");
                        c.CustomAsset("OtherVersion", myAssembly, "WebApplication2.html.OtherVersion.html");
```

### 3. Check the Browser

Now, you're going to ask: what's the URL? I didn't figure it out at
first, but it looks like Swagger uses the file name as the URL. Since
their default page is /swagger/ui/index, my new files' URLs will be
`/swagger/ui/OtherVersion` and
`/swagger/ui/swagger_test`.

The following is one of my new pages, OtherVersion. Isn't this great? As a
developer, when you use another UI framework and you can replace CSS, JavaScript,
and HTML while keeping the original logic, that's just fantastic.

![](http://res.cloudinary.com/dmwrakaup/image/upload/v1458972150/uiblm9hoxxitxz1fgxls.png)

## Add .NET XML Comment for Swagger's API Description

ASP.NET WebAPI's default API helper documentation also looks for the DLL's XML comments
for descriptions. We can do that in Swagger too.

### 1. Project Property

The first thing you need to do is go to the project that contains the API
controller and check the XML documentation file. When building the solution,
Visual Studio will update the XML with comments you add to the class. Also,
Swagger will later read the XML comments as descriptions for the API.

![](http://res.cloudinary.com/dmwrakaup/image/upload/v1459030325/o170ozq0mak76k8hfoqi.png)

### 2. SwaggerConfig Setting

The next important thing is that Swagger has not registered the API XML. You can
add it as follows.

```
c.IncludeXmlComments(string.Format(@"{0}\bin\APIDemo.XML", System.AppDomain.CurrentDomain.BaseDirectory));
```

The following are examples of the WebAPI controller and the API Model class's XML
documentation.

```
///
    /// my product
    ///
    public class Product
    {
        ///
        /// product id
        ///
        public Guid GuidId { get; set; }
        ///
        /// product Id
        ///
        public int ProductId { get; set; }
        ///
        /// product name
        ///
        public string ProductName { get; set; }
        ///
        /// product price
        ///
        public decimal Price { get; set; }
        ///
        /// product unit
        ///
        public int Unit { get; set; }
```

```
///
    /// ProductController API
    ///
    public class ProductController : ApiController
    {
        ///
        /// products data
        ///
        public static ListProducts
        {
            get
            {
                return new List
                {
                    new Product(Guid.NewGuid(), 122, "Product A", 300, 1),
                    new Product(Guid.NewGuid(), 333, "Product B", 400, 10),
                    new Product(Guid.NewGuid(), 444, "Product C", 500, 20),
                    new Product(Guid.NewGuid(), 555, "Product D", 600, 15),
                    new Product(Guid.NewGuid(), 777, "Product E", 700, 5)
                };
            }
        }

        ///
        ///  get values for products
        ///
        ///
        public IEnumerable Get()
        {
            return Products;
        }
```

### 3. Done! Let's Browse the API Documentation

Now we're done. After building the solution, you should see your XML comments
added to the C# class on the Swagger API documentation page.

![](https://d1p0mp3f1fx0hz.cloudfront.net/_iw664rs80.png)

## Conclusion

Swagger with ASP.NET MVC provides very powerful API documentation and it
is very flexible. You can customize the CSS, JavaScript, and HTML while retaining the core Swagger functionality.

Check the
Code
mentioned in this blog.

This walkthrough tutorial is about how to set up Swagger with ASP.NET MVC API by using Visual Studio 2015, also provides steps of how to customize the Swagger UI.

How to Setup and Customize Swagger with ASP.NET MVC


## Table of Contents

1. [Introduction](#introduction)
2. [Example of Log WebAPI MVC3 Controller](#example-of-log-webapi-mvc3-controller)
3. [Conclusion](#conclusion)

## Introduction

This post demonstrates how to log every request, response, and exception when accessing an ASP.NET MVC 3 controller using a custom `ActionFilterAttribute`.

## Example of Log WebAPI MVC3 Controller

The following code creates a `LogFilterAttribute` that captures request parameters, URLs, headers, and response status codes for every controller action.

```
public class LogFilterAttribute : ActionFilterAttribute
    {
        ILog _log;

        public LogFilterAttribute()
            : this(null)
        {
        }

        public LogFilterAttribute(ILog log)
        {
			// TODO: define default ILog Service
            //_log = log ?? SomekindOfDefaultLogService()
        }

        public override void OnActionExecuting(ActionExecutingContext filterContext)
        {
            string controllerNamespace = string.Format("{0} {1}Controller.{2} {3}",
                filterContext.HttpContext.Request.HttpMethod,
                filterContext.ActionDescriptor.ControllerDescriptor.ControllerName,
                filterContext.ActionDescriptor.ActionName, "Request");
            var requestObject = new
            {
                Request = new
                {
                    Parameters = JsonConvert.SerializeObject(filterContext.ActionParameters),
                    Url = filterContext.HttpContext.Request.RawUrl,
                    Headers = JsonConvert.SerializeObject(filterContext.HttpContext.Request.Headers)
                }
            };

            _log.Save(controllerNamespace, JsonConvert.SerializeObject(requestObject));

            base.OnActionExecuting(filterContext);
        }

        public override void OnActionExecuted(ActionExecutedContext filterContext)
        {
            string controllerNamespace = string.Format("{0}Controller.{1} {2}", filterContext.ActionDescriptor.ControllerDescriptor.ControllerName, filterContext.ActionDescriptor.ActionName, "Response");

            var reponseObject = new
            {
                Response = new
                {
                    StatusCode = filterContext.HttpContext.Response.StatusCode,
                    StatusDescription = filterContext.HttpContext.Response.StatusDescription,
                    Exception = JsonConvert.SerializeObject(filterContext.Exception)
                }
            };

            if (filterContext.Exception != null)
            {
                controllerNamespace = controllerNamespace + " Exception";
            }

            _log.Save(controllerNamespace, JsonConvert.SerializeObject(reponseObject));

            base.OnActionExecuted(filterContext);
        }
    }
```

## Conclusion

By using a custom `ActionFilterAttribute`, you can easily log all WebAPI requests and responses in your ASP.NET MVC application. This approach captures request parameters, URLs, headers, response status codes, and any exceptions that occur during controller action execution.


Example code of logging every request, response, and exception when accessing an ASP.NET MVC 3 controller.

WebAPI

How to Setup and Customize Swagger with ASP.NET MVC

How to Log All WebAPI Request Response at ASP.NET MVC
