<p>
  This blog walk through how to use Swagger / OpenAPI to add API document to
  Next.js, a node.js framework. It will cover how to create to API at Next.js
  and add API Document with Swagger by swagger-jsdoc and&nbsp; swager-ui-react.
</p>
<h2>Setup Next.js</h2>
<p>
  You can reference Next.js' official document to get more detail about setup
  Next.js, in this blog we'll set up Next.js with TypeScript.&nbsp;&nbsp;
</p>
<p>
  After running the command at your terminal, follow the steps to finish setup
  the default code.&nbsp;
</p>
<pre class="language-bash"><code>npx create-next-app --typescript</code></pre>
<h3>Install dependencies packages for integrating with Swagger for Next.js</h3>
<p>
  Here, we'll install a list of packages that require to setup swagger API
  document. We'll install <code>swagger-ui-react</code> which use for create
  swagger UI page, use <code>@types/swagger-ui-react</code> since we start
  typescript with next.js, finally we use <code>swagger-jsdoc</code>for generate
  document from the code.&nbsp;
</p>
<pre class="language-bash"><code>npm install --save swagger-ui-react
npm install --save-dev @types/swagger-ui-react swaggerj-jsdoc</code></pre>
<h2>Create API at Next.js</h2>
<p>
  Once we setup the Next.js with default setting, we'll create following simple
  APIs so later we can add swagger to it.&nbsp;
</p>
<ul>
  <li>get all product list - [GET] /product</li>
  <li>get product by id - [GET] /product/:id</li>
  <li>create product - [POST] /product</li>
  <li>update product by id - [PUT] /product/:id</li>
  <li>delete product by id - [DELETE] /product/:id</li>
</ul>
<p>
  First we create this product service to have CRUD function for the product
  services. As, you can see this ProductService has deleteProduct,
  updateProduct, addProduct, getProductById and getAllProducts. We will use
  these service behind our Next.js API.&nbsp;
</p>
<pre class="language-javascript"><code>nterface Product {
    id: number;
    name: String;
    price: number;
}

class ProductService {

    products: Product[];

    private static instance: ProductService;

    private constructor() {
        this.products = [{
            id: 1,
            name: 'apple',
            price: 2
        }, {
            id: 2,
            name: 'banana',
            price: 1.5
        }];
    }

    public static Instance(): ProductService {
        if (!ProductService.instance) {
            ProductService.instance = new ProductService();
        }

        return ProductService.instance;
    }

    getAllProducts(): Product[]  {
        return this.products;
    }

    getProductById(id: number): Product | undefined {
        let result = this.products.filter(_ =&gt; _.id === id);
        if (result.length &gt; 0) {
            return result[0];
        }
        return undefined;
    }

    addProduct(product: Product) {
        let maxId = Math.max(...this.products.map((x) =&gt; x.id));

        this.products.push({
            id: ++maxId,
            name: product.name,
            price: product.price
        });

        return this.products;
    }

    updateProduct(id: number, newProduct: Product) : Product | undefined{
        let result = this.products.find(_ =&gt; _.id === id);
        if (!result) {
            return undefined;
        }

        result.name = newProduct.name;
        result.price = newProduct.price;

        return result;
    }

    deleteProduct(id: number) : Product[] | undefined{
        let index = this.products.findIndex(_ =&gt; _.id === id);
        if (!index) {
            return undefined;
        }

        this.products.splice(index, 1);

        return this.products;
    }
}

export default ProductService;</code></pre>
<h2>Create API</h2>
<p>
  First, we'll create <code>index.ts</code> file under api/product folder, this
  file will handler HTTP Get which will return all the products, POST will
  handler add new product to the existing product service.
</p>
<pre class="language-javascript"><code>export default function handler(
  req: NextApiRequest,
  res: NextApiResponse&lt;any&gt;
) {

  if (req.method === 'GET') {
    res.status(200).json(ProductService.Instance()
    .getAllProducts());
  }
  else if (req.method === 'POST') {
    res.status(200).json(
      ProductService.Instance()
      .addProduct(req.body));
      ;
  }
}</code></pre>
<p>
  Next, we'll create <code>[id].ts</code> to handler dynamic Next.js API. This
  file, will be handler our update, delete and find by the product id
  APIs.&nbsp;
</p>
<pre class="language-javascript"><code>export default function handler(
  req: NextApiRequest,
  res: NextApiResponse&lt;any&gt;
) {

  const {query} = req;

  if (req.method === 'DELETE') {
    res.status(200).json(
      ProductService.Instance()
      .deleteProduct(+query.id));
      ;
  }
  else if (req.method === 'GET') {
    res.status(200).json(
      ProductService.Instance()
      .getProductById(+query.id))
      ;
  }
  else if (req.method === 'PUT') {
    res.status(200).json(
      ProductService.Instance()
      .updateProduct(+query.id, req.body));
      ;
  }
}</code></pre>
<h2>Verify the API</h2>
<p>
  At this point, if you run the following URL, you should be able to see the API
  response.
</p>
<p>
  <img
    src="https://d1p0mp3f1fx0hz.cloudfront.net/upload/2022/1/r1GHg1jCLEK7zeTJ3rSjZ3-153mzc3nb9520220110233250/750-153mzc3nb9520220110233250.png"
    alt="Responsive image"
  />
</p>
<h2>Add Swagger Javascript Comment</h2>
<p>
  This is actually import part to use Swagger UI at Next.js, you write the
  swagger base on the swagger API specification's YAML file format. Later, the
  swagger-jsdoc will read this and generate the swagger.json file for UI to
  use.&nbsp;
</p>
<p>Add this comment to the /api/product's index.ts file.&nbsp;</p>
<pre class="language-javascript"><code>/**
 * @swagger
 * /api/product:
 *   get:
 *     tags:
 *          - Products
 *     description: Get all Product
 *     responses:
 *       200:
 *         description: Success
 */ </code></pre>
<h2>Add Swagger to Next.js</h2>
<p>
  Now, since the API is ready we can start setup our swagger at Next.js. First,
  I would like to show the swagger UI when user type /swagger. So, under the
  pages folder, created swagger.tsx file.&nbsp;
</p>
<p>
  So we you type the <strong>/swagger,</strong> Next.js will try to render
  following page. The page itself is from the Library
  <code>swagger-ui-react</code> package. It has depend on the swagger.json file,
  which we'll create later.&nbsp;
</p>
<p>
  Also, you can see that we import the <code>swagger-ui.css</code> from the
  <code>swagger-ui-react</code> libaray, if you have custom css style you can
  import your style as well.&nbsp;
</p>
<pre class="language-javascript"><code>import { NextPage } from "next";
import SwaggerUI from "swagger-ui-react";
import "swagger-ui-react/swagger-ui.css";

const Home: NextPage = () =&gt; {
  return &lt;SwaggerUI url="/swagger.json"&gt;hi&lt;/SwaggerUI&gt;;
};
export default Home;</code></pre>
<h3>Create swagger.json as part of build command</h3>
<p>
  Following command swagger will run the swagger-jsdoc task which will create
  swagger API specification base on the javascript document comment, then the
  swagger UI will use this json file to build the UI. So as you can see from
  following once create the swagger.json file I move it to the public folder.
</p>
<pre class="language-bash"><code> "scripts": {
    "dev": "next dev",
    "build": "next build",
    "start": "next start",
    "lint": "next lint",
    "swagger": "swagger-jsdoc -d swaggerConfig.js &amp;&amp; mv swagger.json ./public"
  },</code></pre>
<h2>That's should be All</h2>
<p>
  After above setup, write API, add API document comment, setup swagger at
  Next.js, you should be able to see following swagger API document page. Now,
  you can continue to add your API, add the comment base for each API, then
  you'll have this centralize API document to see all the API you have
  created.&nbsp;
</p>
<p>
  <img
    src="https://d1p0mp3f1fx0hz.cloudfront.net/upload/2022/1/uHgCecU8xgtU8Vz3cZfDzd-1p6ervh7ij520220110234502/750-1p6ervh7ij520220110234502.png"
    alt="Responsive image"
  />
</p>
<h2>Conclusion</h2>
<p>
  Swagger, Open API is a popular and easy way to setup API documents, with API
  documents you can easy to review all documents run the API check the API
  specification about support request or response object, test the API.&nbsp;
</p>
<p>
  All the code mentioned here, you can check at here
  <a
    href="https://github.com/keke78ui9/Sample-Code-For-Swagger/tree/master/swagger-expressjs"
    >Github</a
  >.
</p>
